Detailed Product Description
Name: Capacitor & Diode Multiplier Module Rated Voltage: 8KV, 10KV, 12KV, 15KV, 20KV, 25KV, 30KV
Capacitance: 220PF,250pF,330PF,470pF,500pF,1000pF,2400pF,others No. Of Capacitors: 4,5,6,8,10,12, Others
Capacitance Tolerance: 10%(K) Output Voltage: 40kV~150kV
Brand: AnXon Material: Y5T,Y5U,others

Product Description



20KV 330PF 8 array customized high voltage capacitor with diode assembly



Specifications

1, Multiple designs up to 12 stages
2, Voltage ratings of the individual discs from 8 kVdc to 30 kVdc
3, Capacitance ratings of the individual discs from 100pF to 2400pF
4, Stacks with diodes, Other versions on request
5, Small size, Lead (Pb)-free version on request

20KV 330PF 8 array customized high voltage capacitor with diode assembly
20KV 330PF 8 array customized high voltage capacitor with diode assembly

AnXon provide high quality customized ceramic capacitor stacks and High Voltage Ceramic Capacitor Multiplier Sets, Please see below table to select our standard parts.

All the capacitance, voltage, number of stacks, diodes specs can be as your request,

Individual
discs
Capacitance
Individual
discs
Voltage
Number of
Stacks
Ceramic
Dielectric
Diode
for Multiplier
100pF


8kV

10kV

12kV

15kV

20kV

25kV

30kV

others



4 stacks

5 stacks

6 stacks

8 stacks

10 stacks

12 stacks

others





N4700

Y5T

Y5U

others



2CL73 12kV 5mA

2CL74 14kV 5mA

2CL75 16kV 5mA

2CL76 18kV 5mA

2CL77 20kV 5mA

JB99T 20kV 20mA

HVRT150 15kV 30mA

HVRT200 20kV 30mA

others
150pF
220pF
250pF
280pF
310pF
330pF
350pF
470pF
500pF
1000pF
2200pF
2400pF

20KV 330PF 8 array customized high voltage capacitor with diode assembly
20KV 330PF 8 array customized high voltage capacitor with diode assembly




Products Application



Ceramic capacitor stacks have been developed for use in low power voltage multipliers used in high voltage DC generators. The major applications are x-ray equipment for medical diagnostics or electrostatic paint spraying equipment.



HV Voltage Multiplier Unit Application Guide
The major applications are x-ray equipment for:
• Medical diagnosis
• Dentistry x-ray application
• Industrial x-ray for material control
• Airport security x-ray scanner
• Low power voltage multipliers
• High voltage DC generators.
• X-ray equipment for medical diagnostics
Electrostatic paint spraying equipment.
