High Energy Pulses Tubular Excellent Performance Non-inductive High Voltage Resistor

I'm Online Chat Now

High Energy Pulses Tubular Excellent Performance Non-inductive High Voltage Resistor

China High Energy Pulses Tubular Excellent Performance Non-inductive High Voltage Resistor supplier
High Energy Pulses Tubular Excellent Performance Non-inductive High Voltage Resistor supplier High Energy Pulses Tubular Excellent Performance Non-inductive High Voltage Resistor supplier High Energy Pulses Tubular Excellent Performance Non-inductive High Voltage Resistor supplier High Energy Pulses Tubular Excellent Performance Non-inductive High Voltage Resistor supplier

Large Image :  High Energy Pulses Tubular Excellent Performance Non-inductive High Voltage Resistor

Product Details:

Place of Origin: CN
Brand Name: China
Certification: RoHS
Model Number: RI80S High Voltage Resistor

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Price: USD1/PC-USD80/PC
Packaging Details: PE Foam + Carton
Delivery Time: 2-3 Weeks
Payment Terms: Western Union, D/P, T/T, L/C
Supply Ability: 1000000PCS
Detailed Product Description
Product Name: Power Supplies Resistor Rated Power: 5W-500W
Resistance: 50K~999M Packaging: Surface Mount
Application: High Voltage Color: Red, Black , Green
Temperature Coefficient: ≤150ppm/℃ Performance Requirements: R≤ ± (1% R + 0.05Ω)
Reference Standard: GB/T5728-2003 Conditions Of Use: -55 °C - +70 °C

Product Description
High Energy Pulses Tubular Excellent Performance Non-inductive High Voltage Resistor

High Energy Pulses Tubular Excellent Performance Non-inductive High Voltage Resistor

Rated Power: 5W 8W 10W 15W 20W 30W 50W 80W 100W 150W 200W 300W 400W 500W

RI80S Outdrawing
High Energy Pulses Tubular Excellent Performance Non-inductive High Voltage Resistor





Testing





High Energy Pulses Tubular Excellent Performance Non-inductive High Voltage Resistor
Test items
Testing method
GB / T5729 IEC115-1
Performance requirements
Rapid changes in temperature
Lower category temperature - room temperature - upper category temperature - room temperature, 5 cycles each limit temperature is kept 30min
ΔR≤ ± (1% R + 0.05Ω)
Climatic sequence
Dry heat - Damp heat, cyclic - cold - Low pressure - cycle heat - DC load DC voltage is applied Length 1min
ΔR≤ ± (5% R + 0.1Ω)
Terminal Strength
Rally test
ΔR≤ ± (1% R + 0.05Ω)
Resistance to soldering heat
Groove welding method, the bath temperature: 350 ± 10 ℃ time: 3.5 ± 0.5s Immersion depth: 2 ± 0.5mm
ΔR≤ ± (1% R + 0.05Ω)
overload
Applying a 2.5 or 2 times the rated power load 5s
ΔR≤ ± (1% R + 0.05Ω)
Steady heat
Applying a DC voltage (limit voltage of the rated voltage or elements) Length 1min
ΔR≤ ± (5% R + 0.1Ω)
Upper category temperature durability
Resistor on the upper category temperature specified duration 1000h
ΔR≤ ± (5% R + 0.1Ω)

Reference standard

GB/T5728-2003 Fixed Resistors for Use in Electronic Equipment Part I: General Specifications
GB/T2828-2002 batch inspection technology sampling procedures and sampling tables
GB/T2691-1994 resistor capacitor marking method

Conditions of use

1, the cooling method: natural cooling
2, the use of temperature: -55 °C - +70 °C



How To Order



High Energy Pulses Tubular Excellent Performance Non-inductive High Voltage Resistor



Related Products

High Energy Pulses Tubular Excellent Performance Non-inductive High Voltage Resistor

P/N
Rated Power
