Product Name: RF Power Plate Capacitor Application: RF / Microwave
Capacitance: 1000PF Rated Voltage: 25kV
Dielectric: R85, N750 Operating Temp: Erature: -30°C ~ 85°C
Dissipation Factor: Max. 0.08% (1kHz 1V) Temperature Characteristics: -750PPM/°C

Product Description



AnXon CCG81 25KV 1500PF 125KVA Power Disc Ceramic Capacitor for Antenna Communication



Cixi AnXon Electronic Co., Ltd is a leader in the design and manufacture of complex electronic ceramic components and assemblies used in a wide range of applications and cutting edge technologies. AnXon specializes in the development and production of dielectric and ferroelectric materials and components. This range of high voltage RF discs capacitors is fabricated from very low loss CLASS 1 ceramic dielectric materials which permit them to carry very high electrical loads over a wide frequency range.



AnXon CCG81 25KV 1500PF 125KVA Power Disc Ceramic Capacitor for Antenna Communication





P/N Rated Spec Max Current Size(mm)
(A) D H d
CCG81-4 / DT110 25KV 300PF 90KVA 30 110 51 M8
CCG81-6 / DT140 25KV 500PF 90KVA 60 140 52
PEZ140 25KV 600PF 90KVA 45 140 52
PEZ140 25KV 800PF 90KVA 45 140 51
CCG81-7 / DT150 25KV 1000PF 125KVA 60 150 50
CCG81-8 / DT160 25KV 1500PF 125KVA 60 158 48
CCG81-8 / DT160 25KV 2200PF 125KVA 60 158 48
CCG81-6 / DT140 30KV 300PF 90KVA 30 138 51 M8
CCG81-6 / DT140 30KV 500PF 90KVA   140
CCG81-7 / DT150 30KV 500PF 125KVA 150
PE200 / PE210 30KV 1000PF 150KVA 60 200 55 M10
PE200 / PE210 30KV 1500PF 150KVA
PE200 / PE210 30KV 1600PF 150KVA





Related Products



High frequency high power RF ceramic capacitors one stop solutions by AnXon



These capacitors are used in oscillators, coupling circuits or bypass capacitors in industrial or medical high frequency equipment. They are suitable to use as coupling capacitors for transmission line and carrier frequency equipment. X-ray equipment, broadcast equipment, induction heating power supplies (tube and solid state), cable fault finders, plasma generators, RF power supplies, dielectric heating, lasers and more.
