Home ProductsHigh Voltage Diode

China manufacturer 2CL10KV/6A 10KV 6A Rectifiers Microwave High Voltage Diodes

I'm Online Chat Now

China manufacturer 2CL10KV/6A 10KV 6A Rectifiers Microwave High Voltage Diodes

China China manufacturer 2CL10KV/6A 10KV 6A Rectifiers Microwave High Voltage Diodes supplier
China manufacturer 2CL10KV/6A 10KV 6A Rectifiers Microwave High Voltage Diodes supplier China manufacturer 2CL10KV/6A 10KV 6A Rectifiers Microwave High Voltage Diodes supplier China manufacturer 2CL10KV/6A 10KV 6A Rectifiers Microwave High Voltage Diodes supplier China manufacturer 2CL10KV/6A 10KV 6A Rectifiers Microwave High Voltage Diodes supplier China manufacturer 2CL10KV/6A 10KV 6A Rectifiers Microwave High Voltage Diodes supplier

Large Image :  China manufacturer 2CL10KV/6A 10KV 6A Rectifiers Microwave High Voltage Diodes

Product Details:

Place of Origin: China
Brand Name: AnXon
Model Number: 2CL10KV/6A

Payment & Shipping Terms:

Minimum Order Quantity: 100
Price: USD 2-3 /piece
Packaging Details: Plastic bag + Box + Carton
Delivery Time: 5-8 working days
Payment Terms: L/C, T/T, Western Union,PayPal
Supply Ability: 100000 piece per week
Contact Now
Detailed Product Description
Product Name: High Voltage Diode Repetitive Peak Reverse Voltage: 7.5-300KV
Average Forward Current: 0.1-6A Reverse Recovery Time: 80-200nS
Maximum Surge Current: 0.5-120A Peak Forward Voltage: 11-400V
Peak Reverse Current (Irrm1): 20uA Peak Reverse Current (Irrm2): 200uA
Package: Through Hole Operation Temperature: -40~+100℃

Product Description



China manufacturer 2CL10KV/6A 10KV 6A Rectifiers Microwave High Voltage Diodes



Product name: China manufacturer 2CL10KV/6A 10KV 6A Rectifiers Microwave High Voltage Diodes



Items
Symbols
Condition
2CL10KV/6A
Units
Repetitive Peak Reverse Voltage
VRRM
TA=25°C, IR=0.5μA
10
KV
Max Average Forward Current
IFAVM
50Hz at TA=55°C
6
A
Max Reverse Recovery Time
Trr
TA=25°C
 -
nS
Max Surge Current
IFSM

120
A
Max Forward Voltage Drop
VFM
TA=25°C
12
V
Max Reverse Current
IRRM1
TA=25°C & VRRM
20
μA
IRRM2
TA=100°C & VRRM
200
μA
Operating Temperature
Ta

-40~+100
°C
Storage Temperature
Tstg

-40~+120
°C



Out Drawing





China manufacturer 2CL10KV/6A 10KV 6A Rectifiers Microwave High Voltage Diodes



Related Products



China manufacturer 2CL10KV/6A 10KV 6A Rectifiers Microwave High Voltage Diodes



China manufacturer 2CL10KV/6A 10KV 6A Rectifiers Microwave High Voltage Diodes

Application



China manufacturer 2CL10KV/6A 10KV 6A Rectifiers Microwave High Voltage Diodes



Features                                                         Applications
• High speed switching                                      • High voltage, Medium Power
• High voltage power supply                              • High voltage generator
• High reliability design                                      • Small package, Epoxy resin
• Voltage multiplier assembly                             • Microwave Power
